Separated inner water ways
Product Catalog
Zedra Touch sink C-spout Triple Spray
Model: 30219002
Zedra Touch 2019
Technical Specification
Technical Details
Product Description
Touch: activation of water via skin contact
battery supply 6 V lithium-battery,
type CR-P2
CE approved
solenoid valve
fixed value mixing valve
automatically stops after 60 sec. (factory set)
type of protection IP 44
GROHE Long-Life finish
GROHE SilkMove 35 mm ceramic cartridge
Lead and Nickel Free Inner Water Ways
GROHE Magnetic Docking guarantees easy retraction and smooth docking of the spray head back to the starting position
pull-out spray with 3 spray types
diverter: laminar spray/SpeedClean shower jet/GROHE Blade spray (reduced water consumption by up to 70 % and even stronger spray performance)
stop function - pause button to stop the water flow
automatic return to laminar spray
adjustable flow rate limiter
swivel tubular spout
swivel area 360°
protected against backflow
flexible connection hoses
maximum flow rate (at 3 bar): 9 l/min
Style
Contemporary
Installation Type
Deck mounted
Height (mm)
85.0
Length (mm)
590.0
Width (mm)
300.0
Net Weight (kg)
5.315
Gross Weight (kg)
5.315
Colors & Finishes
Chrome
Collection
Zedra Touch 2019
Segment
Grand Luxury
Features & Technologies
Modern Touch Technology
Pull-Out Comfort Shower Head (3 sprays)
GROHE Magnetic Docking
GROHE QuickFix Plus (kitchen tap)
